STT04 DOWNLINK SOFTWARE
USING DOWNLINK SOFTWARE
O - 12
3. Click Utilities and select Test Communication. A message
appears indicating the status of communications.
4. Click OK to exit the test function.
Failed Test
If the communications test fails, verify the following before calling
ABB technical support:
• Make sure the cable is completely connected to the STT04 termi-
nal and the PC.
• Make certain the cable is connected to the correct port on the PC.
Verify the COM port setting using Special Advanced and select
Set COM port.
• Make certain the cable is not faulty. Connect a cable known to be
functional.
• Make sure the STT04 terminal is in remote mode. Refer to
UPLOADING AND DOWNLOADING CONFIGURATIONS in
Section 4 for details.
• Make sure the STT04 terminal has at least 50-percent battery
charge remaining. If it does not, connect and plug in the battery
charger.
CHANGE STT04 NAME
The STT04 terminal is shipped from the factory with the following
name: ABB STT04. It is good practice to change the name of an
STT04 terminal when multiple terminals are in use that have different
configurations. Renaming helps to prevent overwriting the configura-
tions of another terminal. Good practice for database management is
to dedicate a database folder to a specific STT04 terminal.
1. Connect the STT04 terminal to the personal computer.
a. Connect the female end of the RS-232-C (customer supplied)
cable to a vacant RS-232-C port (serial port) on the personal
computer.
b. Connect the male end of the RS-232-C cable to the STT04
terminal.
2. Start the DownLink software. Refer to Start located in this sec-
tion.
3. Click Utilities and select Change STT04 Name.
4. Click in the STT04 Name field.
5. Type an STT04 name using up to 18 characters.
