INTRODUCTION
4 - 1
SECTION 4 - OPERATING PROCEDURES
INTRODUCTION
This section covers the functions of the various keys on the STT04
Smart Transmitter Terminal. Step-by-step procedures illustrate each
function.
This section covers:
• Keypad function table.
• Send configurations.
1
• Get configurations.
1
• View configurations.
1
• Erase configurations.
1
• Change working configurations.
1
• Operational functions:
Special feature.
Monitor.
Status.
Rerange.
Options.
NOTE: 1. These functions apply to all transmitters. The procedures
are not duplicated for each transmitter type. The 600T HART trans-
mitter is used in the example procedures.
The creation and modification of configurations and calibrations are
device specific and therefore are covered in the device specific
appendices of this instruction.
HOW TO USE THE PROCEDURE TABLES
Procedures for each of the functions are presented in tables having
three columns: Key, Display, and Comments. The tables read from
left to right. When the key shown is pressed, the screen shown
directly to the right in the display column appears on the terminal
screen. The comment pertains to that screen. Use the procedure
tables to step through the functions.
OPERATOR/INTERFACE CONTROLS
Table 4-1 provides a description of functions for the keys on the
STT04 terminal.
NOTE: The configure, view, select device and options keys function
without a field device connected to the STT04 terminal. The other
functions are locked out until a field device is connected to the
terminal.
