ABB STT04 User Manual

TZID/AZH POSITIONER
SPECIAL FEATURE
M - 13
Operating Mode
Use this function to change operating modes. The screen flow of this
section applies for TZID/AZH positioners with revision 5.x or greater.
Select YES to save changes.
Key Display Comments
ENTER
MAKE CHANGES
PERMANENT?
NO
→ YES
ENTER
ID TAGNAME
READY
Key Display Comments
Select OPERATING MODE.
Use this screen to select the operating mode.
Select AUTO for automatic adaptation of the control
parameters.
Select FIXED for fixed control parameters.
Select MANUAL for manual actuation of control ele-
ment.
Select LOCAL to switch over the device from an
externally selected operating mode to the internally
selected mode.
Select YES to change modes.
SPECIAL
FEATURE
DEVICE INFORMATION
CONTROL PARAMETERS
CHARACTERIST. CURVE
→OPERATING MODE
ENTER
→ CONTOLLING, AUTO
CONTROLLING, FIXED
MANUAL
LOCAL
ENTER
MAKE CHANGES
PERMANENT?
NO
→ YES
