ABB STT04 User Manual

SMART POSITIONER
CALIBRATION
A - 8
Manual Position Calibration
This procedure applies to Positioner configured for either ANALOG or
DIGITAL. Any differences between the two are noted in the Com-
ments column.
Key Display Comments
This operation will cause a change in output not cor-
responding to the input. Be sure the control loop is in
manual.
Select YES.
Select MAN POSITION CAL.
Make the proper adjustments and press .
NOTE: Refer to Positioner instruction for details on
the calibrations.
Make the proper adjustments and press .
NOTE: Refer to Positioner instruction for details on
the calibrations.
CALI-
BRATE
OUTPUT WILL BE
AFFECTED! PROCEED?
NO
→ YES
ENTER
OUTPUT D/A CAL
INPUT A/D CAL
→ MAN POSITION CAL
AUTO POSITION CAL
ENTER
ADJUST OUTPUT
TO ZERO
THEN HIT ENTER
ENTER
ENTER
ADJUST OUTPUT
TO SPAN
THEN HIT ENTER
ENTER
ENTER
ID TAGNAME
READY
