ABB STT04 User Manual

STT04 DOWNLINK SOFTWARE
USING DOWNLINK SOFTWARE
O - 13
6. Click OK.
Special Advanced
The following subsections describe the menu items of the Special
Advanced selection.
REPORT DIAGNOSTICS
1. Connect the STT04 terminal to the personal computer.
a. Connect the female end of the RS-232-C (customer supplied)
cable to a vacant RS-232-C port (serial port) on the personal
computer.
b. Connect the male end of the RS-232-C cable to the STT04
terminal.
2. Start the DownLink software. Refer to Start located in this sec-
tion.
3. Click Special Advanced and select Report Diagnostics. This func-
tion returns the COM port being used, sector status and available
sector status of the STT04 terminal.
UPGRADE FIRMWARE
Refer to UPGRADES in Section 6.
UPGRADE BOOT CODE
This function is seldom needed and should only be performed when
instructed to do so by ABB technical support.
SET COM PORT
Use this function to change the communication port (COM port) on
the personal computer that will be used for communications between
the PC and the STT04 terminal.
1. Start the DownLink software. Refer to Start located in this sec-
tion.
2. Click Special Advanced and select Set COM Port.
3. Select the desired communication port and click OK.
