STT04 DOWNLINK SOFTWARE
USING DOWNLINK SOFTWARE
O - 9
UPLOAD FROM STT04
Use this function to load configuration files from a connected STT04
terminal to the personal computer.
1. Connect the STT04 terminal to the personal computer.
a. Connect the female end of the RS-232-C cable to a vacant
RS-232-C port (serial port) on the personal computer.
b. Connect the male end of the RS-232-C cable to the STT04
terminal.
2. Start the DownLink software. Refer to Start located in this sec-
tion.
3. Place the STT04 terminal into the remote mode. Refer to
UPLOADING AND DOWNLOADING CONFIGURATIONS in
Section 4 for details.
4. Click Transfer Configurations and select Upload from STT04. A
summary of configurations appears (Fig O-4).
5. Highlight the desired configurations from the STT04 terminal.
Click to select only the configurations you want. Do this until all
the desired configurations are selected.
- or -
TC00966A
Figure O-4. Summary of STT04 Configurations
To Next Page
