SPECIAL FEATURE KEY FUNCTIONS
A - 13
Monitor Key Functions
The following functions apply to the positioner.
Use the monitor function key to monitor:
• Position. • Output air supply (O2).
• Set point. • Air pressure.
• Deviation. • Travel.
• Temperature. • Reverse.
• Input air supply. • Digital input.
• Output air supply (O1).
Key Display Comments
Select a monitoring attribute using the down arrow
key and press .
Additional monitor selections are:
Input air supply
Output air O1 port
Output air O2 port
Air pres
Travel
Reverse
Digital input
Shows a real-time value for the selected variable.
MONITOR
POSITION
SET POINT
DEVIATION
→ TEMPERATURE
ENTER
ENTER
ID TAGNAME
MON. VARIABLE
nnn.nnUNITS
GOOD STATUS
CLEAR
ID TAGNAME
READY
