TZID/AZH POSITIONER
CALIBRATION
M - 8
Spring Action Actuator
This function defines the stop to which the valve is set by the spring
action of a single acting actuator.
Select the appropriate direction of rotation.
NOTE: Direction of rotation is looking into the open
cover of the positioner.
Select YES to make the changes permanent.
Lever zero position is complete.
Key Display Comments
ENTER
LEVER SHAFT
STOP TURNING
→ CLOCKWISE
COUNTER CLOCKWISE
ENTER
MAKE CHANGES
PERMANENT ?
NO
→ YES
ENTER
ID TAGNAME
READY
Key Display Comments
Select SPRING ACTION ACTUA.
Select the appropriate direction.
NOTE: Direction of rotation is looking into the open
cover of the positioner.
Select YES to make the changes permanent.
CALI-
BRATE
AUTOSTROKE
MANUAL RANGE ADJUST
LEVER ZERO POSITION
→SPRING ACTION ACTUA
CALI-
BRATE
LEVER SHAFT/
ACTUATOR TURNING
→ CLOCKWISE
COUNTER CLOCKWISE
ENTER
MAKE CHANGES
PERMANENT ?
NO
→ YES
