ABB STT04 User Manual

TBN581 (ORP/pION) TRANSMITTER
CALIBRATION
L - 4
CALIBRATION
This section details the calibration functions of the STT04 terminal
while interfacing a TBN581 ORP/pION transmitter. There are four
types of calibration functions:
• Process calibration.
• Bench calibration (ORP/pION).
• Bench calibration (mV).
• D-to-A adjust.
NOTES:
1. When calibrating, a field device must be connected to the
STT04 terminal.
2. To change calibration or configuration parameters of a field
device that is connected to an IMFBS01 module, the transmitter
must be taken off-line. This is done at the INFI 90 OPEN console.
Refer to Figure L-2 for an overview of the calibration functions.
Enter up to 6 characters. Use familiar units to
describe the output.
Input the lower range value and press . Input
the upper range value.
Select YES to store the configuration.
The Configuration ID tag name just configured will be
in the upper left corner if the configuration is saved. It
becomes the working configuration.
NOTE: Connect the terminal to a device and send
the configuration (using ) to a device
before calibrating.
Key Display Comments
ENTER
ENTER
SECONDARY UNITS
_nnnnnn
ENTER
SECONDARY L.R.
_nn.nn UNITS
SECONDARY U.R.
nn.nn UNITS
ENTER
ENTER
STORE THIS
CONFIGURATION
NO
→ YES
ENTER
ID TAGNAME
READY
SEND CONFIG
