TZID/AZH POSITIONER
SPECIAL FEATURE
M - 9
SPECIAL FEATURE
The following section details unique special feature functions for the
TZID/AZH positioner.
Device Information
This function shows the current settings of the positioner.
Complete.
Key Display Comments
ENTER
ID TAGNAME
READY
Key Display Comments
Select DEVICE INFORMATION.
Shows revision information about the positioner.
Shows the maximum range of rotation of the lever
arm on the positioner.
Shows the serial number of the positioner as speci-
fied at the factory.
Shows the I/P MODULE setting of the positioner.
Options include: single acting and double acting.
Shows the fail-safe position of the positioner. Options
include fail-freeze, and fail-safe.
SPECIAL
FEATURE
→DEVICE INFORMATION
CONTROL PARAMETERS
CHARACTERIST. CURVE
OPERATING MODE
ENTER
SOFTWARE REVISION
n.n
HARDWARE REVISION
n.n
ENTER
LEVER RANGE:
60
o
ENTER
FINAL ASSEMBLY #:
nnnnnnnn
ENTER
I/P MODULE:
DOUBLE ACTING
FAIL-SAFE POSITION
FAIL-FREEZE
