224 Rockwell Automation Publication 1766-UM001I-EN-P - June 2015

Appendix F MicroLogix 1400 Distributed Network Protocol (DNP3)

Channel 1 Link Layer Configuration

In RSLogix 500/RSLogix Micro, open Channel Configuration in the

MicroLogix 1400 Series B project tree.

To enable DNP3 over IP protocol, check DNP3 over IP Enable in the Channel 1

configuration.
