Allen-Bradley MicroLogix 1400 User Manual

Rockwell Automation Publication 1766-UM001I-EN-P - June 2015 261
MicroLogix 1400 Distributed Network Protocol (DNP3) Appendix F
DNP3 Configuration Files
You can set configuration files for each object. These configuration files allow you
to configure parameters such as Class level and Object Flag bit information for
each element. Only a Binary Data file type can be used for configuration file.
For Binary Input, Double Bit Binary Input and Small BCD type data, you can
configure Class information in the Configuration file. The lower 2 bits in the
elements of the Configuration files are the configuration of Class information to
the relative objects. Other bits are reserved.
Related Configuration Files:
• Binary Input Config File Number
Relationship between MicroLogix Data Files and Configuration Files
MicroLogix Data Files Configuration Files File Type File Number Maximum
Configurable
Elements
Binary Input File Binary Input Config File Only B file 3, 9 to 255 256
Binary Input Online Config File (In Series B)
Double Bit Binary Input File Double Bit Binary Input Config File Only B file 3, 9 to 255 256
Double-Bit Binary Input Online Config File (In Series B)
Binary Output File Binary Output Config File Only B file 3, 9 to 255 256
16-bit Counter File 16-bit Counter Config File Only B file 3, 9 to 255 256
16-bit Counter Threshold Config File (In Series B) Only N file 7, 9 to 255
32-bit Counter File 32-bit Counter Config File Only B file 3, 9 to 255 256
32-bit Counter Threshold Config File (In Series B) Only L file 9 to 255
Frozen 16-bit Counter File Frozen 16-bit Counter Config File Only B file 3, 9 to 255 256
Frozen 32-bit Counter File Frozen 32-bit Counter Config File Only B file 3, 9 to 255 256
16-bit Analog Input File 16-bit Analog Input Config File Only B file 3, 9 to 255 256
16-bit Analog Input Deadband Config File (In Series B) Only N file 7, 9 to 255
32-bit Analog Input File 32-bit Analog Input Config File Only B file 3, 9 to 255 256
32-bit Analog Input Deadband Config File (In Series B) Only L file 9 to 255
Short Floating Point Analog Input
File
Short Floating Point Analog Input Config File Only B file 3, 9 to 255 256
Short Floating Point Analog Input Deadband Config
File (In Series B)
Only F file 8, 9 to 255
16-bit Analog Output File 16-bit Analog Output Config File (In Series B) Only B file 3, 9 to 255 256
32-bit Analog Output File 32-bit Analog Output Config File (In Series B) Only B file 3, 9 to 255 256
Short Floating Point Analog Output
File
Short Floating Point Analog Output Config File (In
Series B)
Only B file 3, 9 to 255 256
Small BCD File Small BCD Class Config File Only B file 3, 9 to 255 256
