Allen-Bradley MicroLogix 1400 User Manual

Rockwell Automation Publication 1766-UM001I-EN-P - June 2015 337
MicroLogix 1400 Distributed Network Protocol (DNP3) Appendix F
Implementation Table
MicroLogix 1400 supports DNP3 Certification Subset Level 2.
The implementation table in this section identifies which object groups and
variations, function codes and qualifiers the device supports in both requests and
responses. The Request and Response columns identify all requests and responses
Request 14 (0x0E) FC_WARM_RESTART No MicroLogix 1400 parses
Request 15 (0x0F) FC_INITIALIZE_DATA No Obsolete
Request 16 (0x10) FC_INITIALIZE_APPL Yes MicroLogix 1400 parses. Clears fault and changes the
controller mode to Remote Program. See Starting and
Stopping User Programs (Mode Change) via DNP3 Network on
page 318.
Request 17 (0x11) FC_START_APPL Yes MicroLogix 1400 parses. Clears fault and changes the
controller mode to Remote Run. See Starting and Stopping
User Programs (Mode Change) via DNP3 Network on page
318.
Request 18 (0x12) FC_STOP_APPL Yes MicroLogix 1400 parses. Changes the controller mode to
Remote Program. See Starting and Stopping User Programs
(Mode Change) via DNP3 Network on page 318.
Request 19 (0x13) FC_SAVE_CONFIG No Deprecated.
Request 20 (0x14) FC_ENABLE_UNSOLICITED Yes MicroLogix 1400 parses
Request 21 (0x15) FC_DISABLE_UNSOLICITED Yes MicroLogix 1400 parses
Request 22 (0x16) FC_ASSIGN_CLASS No
Request 23 (0x17) FC_DELAY_MEASURE Yes MicroLogix 1400 parses. Used for non-LAN
Request 24 (0x18) FC_RECORD_CURRENT_TIME No MicroLogix 1400 parses.Used for LAN
Request 25 (0x19) FC_OPEN_FILE Yes MicroLogix 1400 parses
Request 26 (0x1A) FC_CLOSE_FILE Yes MicroLogix 1400 parses
Request 27 (0x1B) FC_DELETE_FILE Yes MicroLogix 1400 parses
Request 28 (0x1C) FC_GET_FILE_INFO No MicroLogix 1400 parses
Request 29 (0x1D) FC_AUTHENTICATE_FILE Yes MicroLogix 1400 parses
Request 30 (0x1E) FC_ABORT_FILE No MicroLogix 1400 parses
Request 31 (0x1F) FC_ACTIVATE_CONFIG No MicroLogix 1400 parses
Request 32 (0x20) FC_AUTHENTICATE_REQ No MicroLogix 1400 parses
Request 33 (0x21) FC_AUTHENTICATE_ERR No MicroLogix 1400 parses
34 (0x22) to
128 (0x80)
No Reserved.
Response 129 (0x81) FC_RESPONSE Yes MicroLogix 1400 sends
Response 130 (0x82) FC_UNSOLICITED_RESPONSE Yes MicroLogix 1400 sends
Response 131 (0x83) FC_AUTHENTICATE_RESP No MicroLogix 1400 sends
132 (0x84) to
255 (0xFF)
No Reserved.
Function Codes for MicroLogix 1400 Series B Controllers
Message
Type
Function
Code
Name MicroLogix
1400 Support
Description
