Graphic device setup
(DEVICE GRAPHIC SCREEN, )
DEVICE SETUP grap
Address :1/4 Status :en State :NML
CommQlt :100% FldType :OPT FldDt :30 ARI
TestVal :255 FldAvg :35 Obsc. :0.0%/m
Alarms :0 High :64 12/01 08:57
Contam. :0% Low :20 12/01 00:05
more X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Device Menu Page 78
Press [More ] to return to Device Graphics Page 103
Press [More ], [More ] to return to the Device Graphic Screen Page 106
The statistics of the device selected in the Device Graphic screen is displayed.
This screen is identical to the screen obtained in Device Setup for smoke and heat
detectors. *See Page 83 for information about device statistics.
To Next Page
