Output definition – type Zone
(INPUT/OUTPUT, 2, )
OUTPUT DEFINITION State :false
Output :1 Trig. :latched
Type :Zone Mode :normal
Zone :1 continuous
Fct. :Fire MCP unlogged
0. .9, ^V, <>, E, X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Input/Output Menu Page 109
Place cursor at TYPE
Select Type: ZONE and press (Unlock memory!)
Select the Function
*See Common Facilities - All Output Types, Page 128 for description of Output, State,
Trigger, Mode, Event and Text
Outputs can activate zones for the following functions. For this type the zone number
must also be specified.
List of Functions:
Fire MCP (manual call point)
Fire Auto
Fault
Coincidence
Condition
Disable
Trigger: Latched/unlatched
Mode: Normal only
Continuous only
Unlogged only
Text: Not applicable
* See Output Description in the Serial Communication Format
