Input definition – type Network
(INPUT/OUTPUT, 1, )
INPUT DEFINITION State :false
Input :1 Trig. :latched
Type :Network Mode :active
Node :01/04 continuous
Output :1 Event unlogged
0. .9, ^V, <>, E, X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Input/Output Menu Page 109
Place cursor at TYPE
Select Type: NET and press (Unlock memory!)
Select the function
*See Common Facilities - All Input Types, Page 111 for description of Input, State,
Trigger, Mode, Event, and Test
This input definition is used for inter-panel input on the network. The input will be
switched by the output of another node (panel) connected on the network.
Node: The node ID from which input is received
Output: The output number setup in the output definition of the selected node.
Trigger: Latched/Unlatched
Mode: Passive/Active
Always continuous
Event: Unlogged/Logged/Fire/Fault/Condition
Text: Allowed
* See Input Description in the Serial Communication Format
