Site Version
(CONFIGURATION 1, , )
SITE VERSION
Vers. Date Time Check
Site : 00020 24.11.00 09:20:44 10683
Block :20 00001 24.11.00 08:51:04 30394
more 0. .9, <>, E, X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Configuration Menu Page 26
Press [More ] to view Hardware Configuration 2 Page 31
This menu displays the self-diagnostic data of the FP2000 system.
Site -
The site refers to the panels itself and vers. to the amount of times data has been
changed since the last time the event buffer has been cleared. The date and the time
refer to when last the data on the firepanel was changed. The check column refers to the
checksum, in decimal format, that was calculated after the last time the panel was
changed.
Block –
Each function of the firepanel has data that is stored in different blocks in the memory.
There are 23 of these blocks, which is handled just as the site information except that
each individual block is tracked independently.
