Aritech FP2000 Series Reference Guide

Output definition – type Area
(INPUT/OUTPUT, 2, )
OUTPUT DEFINITION State :false
Output :1 Trig. :latched
Type :Area Mode :normal
Area :1 continuous
Fct. :Fire unlogged
0. .9, ^V, <>, E, X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Input/Output Menu Page 109
Place cursor at TYPE
Select Type: AREA and press (Unlock memory!)
Select the Function
*See Common Facilities - All Output Types, Page 128 for description of Output, State,
Trigger, Mode, Event and Text
An area is defined as a group of zones (see Page 99). An output can activate a condition
in an area by specifying the area number 1-99, and the function. Area functions could be
latched or unlatched, but not reported as an event.
List of Functions:
Fire
Fault
Coincidence
Condition
Disable
-
An area coincidence is two or more zones allocated to the area in a fire alarm condition. It
is independent of zones in coincidence. *See Page 99
Trigger: Latched/unlatched
Mode: Normal only
Continuous only
Unlogged only
Text: Not applicable
* See Output Description in the Serial Communication Format
