Aritech FP2000 Series Reference Guide

Loop test 2 – parameter screen 2
(LOOP TEST 2, START TEST, )
For "SINGLE" device test, the display will be as follows:
LOOP TEST :Single Device on A Side
L Val Typ Adr St Ck L Val Typ Adr St Ck
1 0 0 0 0 0 5 0 0 0 0 0
2 0 0 0 0 0 6 0 0 0 0 0
3 0 0 0 0 0 7 0 0 0 0 0
4 0 0 0 0 0 8 0 0 0 0 0
X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 TDO
L - Loop number
Val - Device analogue value
Typ - Device type
0 - NONE
1 - MCP
2 - OPT
3 - ION
4 - reserved
5 - OPT
6 - ION
7 - HEAT
8 - ICC
9 - I/O
10 - reserved
11 - reserved
Adr - Device address
St - Device state
0 - NO ALARM
1 - DEVICE IN ALARM
Ck - Device checksum
Not implemented
