User's Manual 1054 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
Parameter Description
of the parameter minus 1.
The valid range is -1 to 1,000. The default is -1 (i.e., not used).
Note:
 The parameter is applicable only to analog interfaces.
 It is assumed that all Call Waiting Tones are defined in
sequence in the CPT file.
 SIP Alert-Info header examples:
Alert-Info:<Bellcore-dr2>
Alert-Info:<http://…/Bellcore-dr2> (where "dr2" defines call
waiting tone #2)
 The SIP INFO message is according to Broadsoft's application
server definition. Below is an example of such an INFO
message:
INFO sip:06@192.168.13.2:5060 SIP/2.0
Via:SIP/2.0/UDP
192.168.13.40:5060;branch=z9hG4bK040066422630
From:
<sip:4505656002@192.168.13.40:5060>;tag=1455352915
To: <sip:06@192.168.13.2:5060>
Call-ID:0010-0008@192.168.13.2
CSeq:342168303 INFO
Content-Length:28
Content-Type:application/broadsoft
play tone CallWaitingTone1
62.10.5.3 Call Forwarding Parameters
The call forwarding parameters are described in the table below.
Table 62-44: Call Forwarding Parameters
Parameter Description
Enable Call Forward
configure voip > gateway
dtmf-supp-service supp-
service-settings > call-
forward
[EnableForward]
Enables call forwarding.
 [0] Disable
 [1] Enable (Default)
For FXS interfaces, the Call Forward table (FwdInfo parameter) must be
configured to use the Call Forward feature. The device uses SIP REFER
messages for call forwarding.
Note:
 To use this service, the devices at both ends must support call
forarding.
 For the device to respond to SIP 3xx responses with a new SIP
request (forwarding the original request), configure the parameter to
.
Call Forwarding Table
Call Forwarding Table
configure voip > gateway
analog call-forward
[FwdInfo]
Defines call forwarding of IP-to-Tel calls (using SIP 302 response) to
other device ports or an IP destination, based on the device's port to
which the call was originally routed.
The format of the ini file table parameter is as follows:
