Barco PHWU-81B User Manual

11. Maintenance
FILTER MENU
ENTER
Image 11-1
3. Press the ENTER key.
4. Select CLEANUP PE RIOD by pressing the ▲ or ▼key.
CLEANUP PERIOD
1 WEEK
Image 11-2
5. Select 24H or 1WEEK by pressing the ◄ or ► key.
24H
The filter is cleaned about every 24 hours.
1WEEK
The filter is cleaned about every 168 hours.
6. Press the ENTER key.
When you select 24H
or 1WEEK , the box to set the c leaning interval is displayed.
24H
24H
0
OK
CLEAR
DEL
CANCEL
123456 78 9
← →
NEXT CLEANUP
Image 11-3
1WEEK
0
OK
CLEAR
DEL
CANCEL
123456 78 9
← →
7D 00H
NEXT CLEANUP
Image 11-4
7. Move the key cursor using the direction keys to select the number you want to enter and then press the ENT ER key.
Maximum interval
24H
24H (about 24 hours)
1WEEK
7D 00H (about 168 hours)
← key Shifting the p osition of enter cursor to the left for each c haracter.
→ key Shifting the position of enter cursor to the right for each c haracter.
DEL k ey Deleting the character in the position of enter cursor for each character.
CLEAR ke y Deleting all the entered c haracters.
When the v alue y ou entered meets the following conditions, an error dialog b ox is display ed at the screen c enter for 3 sec onds.
- The value has been cleared by DEL or CLE AR and left blank.
- The value yo u entered is out of the setting range.
24H
25H or over
1WEEK
7D 01H or over
100
R5905597 PHXX SERIES 20/05/2014

Barco PHWU-81B Specifications

General

Matrix size	0.67 \
Matrix type	DMD
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	2800:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Projector brightness (economic mode)	5450 ANSI lumens
Focal length range	- mm
Lamp power	350 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	4000 h
Full HD	No
Supported graphics resolutions	1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
Ethernet LAN data rates	10, 100 Mbit/s
I/O ports	SDI
Noise level	44 dB
Noise level (economic mode)	39 dB
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black, White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	910 W
Power consumption (standby)	0.3 W
Power consumption (economy mode)	690 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 90 %

Weight and Dimensions

Depth	660 mm
Width	510 mm
Height	263 mm
Weight	21000 g
Package depth	840 mm
Package width	650 mm
Package height	415 mm
Package weight	26500 g
