Barco PHWU-81B User Manual

5. Advanced menu
Item
Setting
Function
DVI LONG CABLE AUTO Select this option for normal use.
MANUAL
Use to adjus t the amount of transmiss ion signal correction w hen a
long D VI cable is used.
REMOTE 1 MODE
ENTER
Select when c ontrolling the projector by a control panel conn ected to
the REM O T E 1 IN terminal.
PIN 1
GND Unc hangeable. (Fixed.)
PIN 2
POWER / NONE Select POWER or NONE .
PIN 3
COMPUTER 1
PIN 4
COMPUTER 2
PIN 5
VIDEO
PIN 6
S-VIDE O
PIN 7 DVI
You can assign CO MP UTER 1, COM PUT ER 2, VIDEO , S-V IDEO,
DVI, HDM I, SDI (for PHW U-81B only), or NONE to each pin. Though
the assignment can be dup licated, the pins so assigned become
invalid and their settings are displayed with asterisks at both ends
(like “*COMPU T ER 1*”).
PIN 8 BLANK / NONE Select BLANK or NONE.
PIN 9 ON/OFF Unchangeable. (Fixed.)
RESET
OK
Settings are reset to the defaults.
FILTER MENU
ENTER
The filter menu for the following settings is displayed.
CLEANUP PERIOD
24H
/1WEEK /OFF
You can set the filter cleaning interval.
MANUAL CLEANUP
OK
Select this option to clean the filter im mediately.
• When STANDBY MODE in the INSTA LLATION 1 menu is LO W, you cannot select REMOTE 1 M OD E.
5.6 Multi-Screen menu
Overview
IMAGE INSTALL1 INSTALL2
MULTI-
SCREEN
FEATURE SIGNAL NETWORK INFO
EDGE BLENDING
SETTING
OFF
OFF
EDGE ADJUST
COLOR MATCHING
SETTING
MEASURED DATA
MANUAL
MEASURE
Image 5-16
Item Setting Function
EDGE BLENDING OFF S elect when using the p rojector alone
ON Select when using the projector to c onfi gure the multi-screen
consisting of multiple projec tors.
The following settings in the S ET TING b ecom e enabled to make the
overlapped area of the dis played images unnoticeable.
SETTING
EDGE ADJUST
Use to make the overlapped area of the screens unnoticeable in the
multi-screen application. Use this setting to select the edges to be
overlapped or to s et the ov erlapped areas.
BLACK LEVEL
In the multi-screen application, the black level in the areas where
images are overlapped will bec ome bright. So, use this setting to
adjust the black level in non-overlapped areas.
BRIGHT UNIFORMITY
CORRECTION
Use to correct non-uniformity in the s creen brightness of the single
projector to facilitate edge blending.
46
R5905597 PHXX SERIES 20/05/2014

Barco PHWU-81B Specifications

General

Matrix size	0.67 \
Matrix type	DMD
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	2800:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Projector brightness (economic mode)	5450 ANSI lumens
Focal length range	- mm
Lamp power	350 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	4000 h
Full HD	No
Supported graphics resolutions	1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
Ethernet LAN data rates	10, 100 Mbit/s
I/O ports	SDI
Noise level	44 dB
Noise level (economic mode)	39 dB
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black, White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	910 W
Power consumption (standby)	0.3 W
Power consumption (economy mode)	690 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 90 %

Weight and Dimensions

Depth	660 mm
Width	510 mm
Height	263 mm
Weight	21000 g
Package depth	840 mm
Package width	650 mm
Package height	415 mm
Package weight	26500 g
