Barco PHWU-81B User Manual

5. Advanced menu
Item
Setting
Function
GEOMETRY
ENTER
The geom etry adjustment me nu is displayed.
TEST PATTERN
ENTER
The test pattern is displayed.
SPLIT (for PHWU-81B/
PHW X-81B only)
ENTER
The split screen is d isplayed.
PIP (for PHXG-91B only)
ENTER
The picture-in-picture (PIP) screen is displayed.
AUTO PO SITION
ENTER
The au to position function is activated.
• Regardless of the setting of LAMP MODE, the STANDARD lam p m ode is activated by default w heneve r the projector is turned
on. When LA MP MODE has been set to LOW, the lamp mode changes from STA NDARD to LOW about 2 m inutes after turn-on.
• When the am bient operating tem perature is high, the brightness of the lamp isn’t changed by switching the lamp mode.
• When the lamp m ode is switched, the projected image ma y flicker.
• Frequent switching of the lamp m ode may damage the lamp.
• When using the projector for a long time, set LAMP RELAY.
• While the lam ps are being warm ed up, an icon is displayed to the right of the INSTA LLATION 1 me nu bar. While the ic
on
is being displayed, you canno t set LAMP S ELE CT and LAMP RELAY. And an icon is d isplayed while the operating ambient
temperature is high. W hile the icon is b eing displayed, the lamp may not brighten even when you change the LAM P MODE to
STANDARD.
• After you switch the lamps and the newly selected lam p turns o n, you ca nnot turn off the projector for approx. 1 minute.
5.5 Installation 2 m enu
Overview
16:10
IMAGE INSTALL1 INSTALL2
MULTI-
SCREEN
FEATURE SIGNAL NETWORK INFO
REMOTE 1 MODE
FILTER MENU
AUTO POWER ON
AUTO POWER OFF
OFF
ON
AUTO
5min
IMAGE CAPTURE
SPLASH SCREEN
DVI LONG CABLE
BACK COLOR
ENTER
ENTER
SETUP
SCREEN
Image 5-15
Item
Setting
Function
AUTO POW ER ON ON / OFF When ON is chosen, the projector is automatically turn on when the
power cord is plugged in the wall outlet. Choose ON when using the
projector mounted on the ceiling.
→ The projector is in the stand-by m ode when the lamp is o ff. Use the
remote control to turn on the lamp.
AUTO POW ER OFF OFF / 5m in-8hour When no video signal is input and no oper ation is m ade, the projector
automatically turns off after the selected time period. A dialog is
displayed 5 minutes before the p rojector turns off.
SCREEN 16:10 (For P HW U-
81B/PHWX-81B only)
Select this setting w hen using a 16:10 screen.
16:9 Select this setting when using a 16:9 screen.
4:3 Select this setting when using a 4:3 screen.
IMAGE CAP TU RE
SETUP
This projector does not support th
is function.
SPLASH SCREEN ON Fixed to ON.
BACK COLOR BLUE / BLACK / IMAGE Use to select the b ackground from am ong BLUE, BLACK and IMAGE,
which will be displayed when there is no signal input from the source.
When IMAGE is selected, the splash image will be disp layed.
R5905597 PHXX SERIES 20/05/2014
45

Barco PHWU-81B Specifications

General

Matrix size	0.67 \
Matrix type	DMD
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	2800:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Projector brightness (economic mode)	5450 ANSI lumens
Focal length range	- mm
Lamp power	350 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	4000 h
Full HD	No
Supported graphics resolutions	1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
Ethernet LAN data rates	10, 100 Mbit/s
I/O ports	SDI
Noise level	44 dB
Noise level (economic mode)	39 dB
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black, White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	910 W
Power consumption (standby)	0.3 W
Power consumption (economy mode)	690 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 90 %

Weight and Dimensions

Depth	660 mm
Width	510 mm
Height	263 mm
Weight	21000 g
Package depth	840 mm
Package width	650 mm
Package height	415 mm
Package weight	26500 g
