Configuring Quality of Service (QoS)

Configuring QoS Port-Based Settings

Cisco CVR100W Wireless-N VPN Router Administration Guide 116

Configuring QoS Port-Based Settings

You can configure QoS settings for each LAN port on the CVR100W. The

CVR100W supports 4 priority queues that allow for traffic prioritization per

physical switch port.

To configure QoS settings for the LAN ports:

STEP 1 Choose QoS > QoS Port-Based Settings.

STEP 2 For each port in the QoS Port-Based Settings table, enter the following

information:

STEP 3 Click Save.

STEP 4 To restore the default port-based QoS settings, click Restore Default. Then, click

Save.

Trust Mode Choose one of the following options from the drop-

down menu:

• Port: This setting enables the port based on

QoS. You can then set the traffic priority for a

particular port. The traffic queue priority starts

at the lowest priority of 1 and ends with the

highest priority of 4.

• DSCP: Differentiated Services Code Point

(DSCP). Enabling this feature prioritizes the

network traffic across the LAN based on the

DSCP queue mapping on the DSCP Settings

page.

• CoS: Class of Service (CoS). Enabling this

feature prioritizes the network traffic across the

LAN based on the CoS queue mapping on the

CoS Settings page.

Default Traffic

Forwarding Queue

for Untrusted

Devices

Choose a priority level for outbound traffic (1 to 4).
