Introduction
Connecting the CVR100W
Cisco CVR100W Wireless-N VPN Router Administration Guide 14
1
Wall Mounting
The CVR100W can be wall-mounted. The wall-mounting hardware is
user-supplied. The ports on the back panel must face either upward or downward
when mounting the CVR100W to a wall.
WARNING Insecure mounting might damage the device or cause injury. Cisco is not
responsible for damages incurred by insecure wall-mounting.
Connecting the CVR100W
By default, the wireless module of the CVR100W is enabled. For the initial
configuration, we recommend that you connect to the CVR100W with an Ethernet
cable. Of course, you can also use a wireless connection. To connect the PC to the
CVR100W's wireless network for the first time, use the default SSID name and
pre-shared key that are provided on the product label at the bottom of the
CVR100W. See Connecting to Your Wireless Network for more information.
STEP 1 Power off all equipment, including the cable or DSL modem, the PC that you will
use to connect to the CVR100W, and the CVR100W itself.
STEP 2 Connect the supplied power adapter to the 12VDC port on the back panel of the
CVR100W. Plug the other end of the power adapter into an electrical outlet. Make
sure that the POWER button is turned off.
CAUTION Use only the power adapter that is supplied with the unit. Using a different power
adapter could damage the unit.
STEP 3 Connection one end of an Ethernet cable to your cable or DSL modem. Connect
the other end to the WAN port on the back panel.
STEP 4 Connect one end of a different Ethernet cable to one of the LAN ports on the back
panel. Connect the other end to an Ethernet port on the PC that you will use to run
web-based Configuration Utility.
NOTE Skip this step if you want to connect the PC to the CVR100W through a
wireless connection.
