Viewing CVR100W Status
Viewing System Summary
Cisco CVR100W Wireless-N VPN Router Administration Guide 25
2
Viewing System Summary
The System Summary page displays a summary of the CVR100W’s settings.
To view a summary of system settings:
STEP 1 Choose Status > System Summary.
STEP 2 From the Refresh Rate drop-down menu, choose a refresh rate.
WAN (Internet) Information
To view complete WAN settings, click details. See Configuring WAN Settings
for more information.
MAC Address MAC address of the WAN port.
IPv4 Address IPv4 address of the WAN port.
IPv6 Address IPv6 address of the WAN port (if IPv6 is enabled).
State Shows if the WAN port is active or inactive for routing.
If the WAN port is active for routing, the WAN state
shows “Up.” If the WAN port is inactive for routing, the
WAN state shows “Down.”
NOTE The state “Down” means that the network
detection fails.
Wireless
Displays the status of all four predefined SSIDs. To view complete wireless
settings, click details. See Viewing Wireless Statistics for more information.
Signal Strength Shows if the Wi-Fi signal strength is 100%, 50%, or
off.
cisco-xxxx Shows if the predefined SSID is enabled or disabled.
VPN
QuickVPN Users Number of QuickVPN users.
