Cisco CVR100W Administration Guide

Configuring Network
Configuring WAN Settings
Cisco CVR100W Wireless-N VPN Router Administration Guide 40
3
STEP 4 (Optional) To configure other optional settings, see Configuring Optional
Settings.
STEP 5 Click Save.
Configuring Static IP
If your ISP assigned you a permanent IP address, perform the following steps to
configure your WAN settings:
STEP 1 Choose Networking > WAN > Internet Setup.
STEP 2 From the Internet Connection Type drop-down menu, choose Static IP.
STEP 3 In the Static IP Settings area, enter the following information:
Keep Alive When you select this option, the Internet connection is
always on.
If you click Keep Alive, enter the number of seconds
that the CVR100W attempts to reconnect after it is
disconnected in the Redial period field.
Authentication Type Choose the authentication type:
• Auto Negotiation: The server sends a
configuration request specifying the security
algorithm set on it. Then, the CVR100W sends
back authentication credentials with the
security type sent earlier by the server.
• PAP: The CVR100W uses the Password
Authentication Protocol (PAP) to connect to the
ISP.
• CHAP: The CVR100W uses the Challenge
Handshake Authentication Protocol (CHAP)
when connecting with the ISP.
• MS-CHAP or MS-CHAPv2: The CVR100W
uses Microsoft Challenge Handshake
Authentication Protocol when connecting with
the ISP.
