Configuring Network
Configuring Routing
Cisco CVR100W Wireless-N VPN Router Administration Guide 48
3
Configuring a DMZ Host
The CVR100W supports demilitarized zones (DMZ). A DMZ is a subnetwork that is
open to the public but behind the firewall. A DMZ allows you to redirect packets
going to your WAN port IP address to a particular IP address in your LAN.
We recommended that you place hosts that must be exposed to the WAN (such as
web or e-mail servers) in the DMZ network. You can configure firewall rules to
allow access to specific services and ports in the DMZ from both the LAN or WAN.
In the event of an attack on any of the DMZ nodes, the LAN is not necessarily
vulnerable.
You must configure a fixed (static) IP address for the endpoint that you designate
as the DMZ host. You should assign the DMZ host an IP address in the same
subnet as the CVR100W’s LAN IP address, but it cannot be identical to the IP
address given to the LAN interface of this gateway.
To configure DMZ:
STEP 1 Choose Networking > LAN > DMZ Host.
STEP 2 Check Enable to enable DMZ on the network.
STEP 3 From the VLAN drop-down menu, choose the VLAN where DMZ is enabled.
STEP 4 In the Host IP Address field, enter the IP address of the DMZ host.
STEP 5 Click Save.
Configuring Routing
Configuring Operating Mode
To configure the CVR100W’s operating mode:
STEP 1 Choose Networking > Routing.
STEP 2 In the Operating Mode field, select one of the following options:
