Cisco MWR 2941 Router Command Reference, Release 15.0(1)MR
show xconnect
611
Cisco MWR 2941 Router Command Reference, Release 15.0(1)MR
OL-23890-01
Usage Guidelines The show xconnect all command can be used to display, sort, and filter basic information about all
xconnect attachment circuits and PWs.
You can use the show xconnect all command output to help determine the appropriate steps to
troubleshoot an xconnect configuration problem. More specific information about a particular type of
xconnect can be displayed using the commands listed in the Related Commands table.
Examples The following example shows show xconnect all command output in the brief (default) display format.
The output shows information about the interfaces and VCs that have been configured to transport
various Layer 2 packets on the router.
Router# show xconnect all
Legend: XC ST=Xconnect State, S1=Segment1 State, S2=Segment2 State
UP=Up, DN=Down, AD=Admin Down, IA=Inactive, NH=No Hardware
XC ST Segment 1 S1 Segment 2 S2
ST Segment 1 S1 Segment 2 S2
------+---------------------------------+--+---------------------------------+--
UP ac Et0/0(Ethernet) UP mpls 10.55.55.2:1000 UP
UP ac Et1/0.1:200(Eth VLAN) UP mpls 10.55.55.2:5200 UP
IA pri ac Et1/0.2:100(Eth VLAN) UP ac Et2/0.2:100(Eth VLAN) UP
UP sec ac Et1/0.2:100(Eth VLAN) UP mpls 10.55.55.3:1101 UP
Cisco IOS XE
Release 2.1
This command was integrated into Cisco IOS XE Release 2.1.
12.4(19)MR2 This command was integrated into Cisco IOS Release 12.4(19)MR2.
12.2(33)MRA This command was integrated into Cisco IOS Release 12.2(33)MRA.
15.0(1)MR This command was integrated into Cisco IOS Release 15.0(1)MR.
Release Modification
