120 Configuring System Information
The following is an example of the CLI commands:
Defining IPv6 Default Gateway
The IPv6 Default Gateway Page provides the ability to manually configure the router of all off-link
traffic. The default gateway address is an interface that serves as an access point to another network.
For IPv6, the configuration of the default gateway is not mandatory, as hosts can automatically learn of
the existence of a router on the local network via the router advertisement procedure.
Unlike IPv4, the IPv6 default gateway can have multiple IPv6 addresses which may include up to one
user-defined static address and multiple dynamic addresses learned via router solicitation message.
The user-defined default gateway has a higher precedence over an automatically advertised router.
When removing an IP interface, all of its default gateway IP addresses are removed.
Dynamic IP addresses cannot be removed.
An Alert message appears once a user attempts to insert more than one user-defined address.
An Alert message appears when attempting to insert a none Link Local type address.
console# show ipv6 interface vlan 1
Number of ND DAD attempts: 1
MTU size: 1500
Stateless Address Autoconfiguration state: enabled
ICMP unreachable message state: enabled
MLD version: 2
IP addresses Type DAD State
------------------------ ------ -----------
fe80::232:87ff:fe08:1700 linklayer Active
ff02::1 linklayer N/A
ff02::1:ff08:1700 linklayer N/A
console(config)# ipv6 icmp
error-interval ICMP errors rate limiting
console(config)# ipv6 icmp error-interval
<0-2147483647> The time interval between tokens being placed
in the bucket in milliseconds
console(config)# ipv6 icmp error-interval 100
<1-200> The maximum number of tokens stored in the bucket
