278 Configuring Device Information
Configuring Ports
The Ports page contains links to port functionality pages including advanced features, such as Storm
Control and Port Mirroring. To open the Ports page, click Switch → Ports.
Defining Port Parameters
The Port Configuration page contains fields for defining port parameters. To open the Port
Configuration page, click Switch → Ports → Port Configuration in the tree view.
Figure 7-22. Port Configuration
• Port — The port number for which port parameters are defined.
•
Description (0-64 Characters) — A brief interface description, such as Ethernet.
•
Port Type — The type of port.
•
Admin Status — Enables or disables traffic forwarding through the port. The new port status is
displayed in the
Current Port Status field.
•
Current Port Status — Specifies whether the port is currently operational or non-operational.

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
