Dell PowerConnect 5424 User Manual

Configuring System Information 207
The following is an example of the CLI commands:
Defining Communities
Access rights are managed by defining communities in the Community Table. When the community
names are changed, access rights are also changed. To open the SNMP Community page, click System →
SNMP → Community in the tree view.
Figure 6-92. SNMP Community
• SNMP Management Station — A list of management station IP addresses.
•
Community String — Functions as a password and used to authenticate the selected management
station to the device.
console (config) # snmp-server user John user-group auth-md5 1234
console (config) # end
console (config)# show snmp users
Name Group Name Auth Method Remote
------- ---------- ----------- ------
John user-group md5

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
