Dell PowerConnect 5424 User Manual

Configuring System Information 139
The following is an example of the CLI commands:
console# enable
console# configure
console (config)# ip host accounting.abc.com 176.10.23.1
Configuring ARP
The Address Resolution Protocol (ARP) is a TCP/IP protocol that converts IP addresses into physical
addresses. The static entries can be defined in the ARP Table. When static entries are defined,
a permanent entry is entered and used to translate IP addresses to MAC addresses. To open the ARP
Settings page, click System→ IP Addressing→ ARP in the tree view.
Figure 6-44. ARP Settings
clear host {name | *} Deletes entries from the host name-to-address cache.
show hosts [name] Displays the default domain name, list of name server hosts, the
static and the cached list of host names and addresses.
Table 6-26. Domain Host Name CLI Commands (continued)
CLI Command Description

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
