200 Configuring System Information
Defining SNMP Views Using CLI Commands
The following table summarizes the equivalent CLI commands for defining fields displayed in the
SNMPv3 View Settings page.
The following is an example of CLI commands:
Defining SNMP Access Control
The Access Control Add Group page provides information for creating SNMP groups, and assigning
SNMP access control privileges to SNMP groups. Groups allow network managers to assign access rights
to specific device features, or features aspects. To open the Access Control Group page, click System→
SNMP → Access Control in the tree view.
Figure 6-85. SNMP View CLI Commands
CLI Command Description
snmp-server view
view-name oid-tree
{included | excluded}
Creates or updates a view entry.
show snmp views [
viewname ] Displays the configuration of views.
Console (config)# snmp-server view user1 1 included
Console (config)# end
Console # show snmp views
Name OID Tree Type
------------- ----------------- --------
user1 iso included
Default iso included
Default snmpVacmMIB excluded
Default usmUser excluded
Default rndCommunityTable excluded
DefaultSuper iso included

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
