Dell PowerConnect 5424 User Manual

136 Configuring System Information
The following is an example of the CLI commands:
Mapping Domain Host
The Host Name Mapping page provides parameters for assigning static host names IP addresses.
The Host Name Mapping page provides up to eight IP addresses per host. To open the Host Name
Mapping page, click System → IP Addressing → Host Name Mapping.
Figure 6-41. Host Name Mapping
• Host Name — Contains a Host Name list. Host Name are defined in the Add Host Name Mapping
page. Each host provides up to eight IP address. The field values for the Host Name field are:
•
IP Address (X.X.X.X) — Provides up to eight IP addresses that are assigned to the specified host name.
•
Ty p e — The IP address type. The possible field values are:
–
Dynamic — The IP address was created dynamically.
–
Static — The IP address is a static IP address.
•
Remove Host Name — When checked, removes the DNS Host Mapping.
console> enable
console# configure
console (config)# ip domain-name www.dell.com

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
