284 Configuring Device Information
Configuring Load Balancing
Load Balancing enables the even distribution of data and/or processing packets across available network
resources. For example, load balancing may distribute the incoming packets evenly to all servers, or redi-rect
the packets to the next available server. Load Balancing is configured on the "LAG Configuration" on
page 285 page.
LAGs can be configured according to the following load balancing types: Layer 2, or Layer 2 and Layer 3
or Layer3.
The LAG Configuration page contains fields for configuring parameters for configured LAGs.
The device supports up to eight ports per LAG, and eight LAGs per system.
For information about Link Aggregated Groups and assigning ports to LAGs, refer to Aggregating Ports.
To open the LAG Configuration page, click Switch→ Ports→ LAG Configuration in the tree view.
If port configuration is modified while the port is a LAG member, the configuration change is only
effective after the port is removed from the LAG.
Console# show interfaces status
Port Type Duplex Speed Neg Flow
Control
Link
State
Back
Pressure
Mdix
Mode
---- ----- ------ ------ ---- ------ ----- ------ ----
g1 1G Full 100 Auto On Up Enable On
g1 100 Full 100 Off Off Down Disable Off
g2 100 Full 1000 Off Off Up Disable On
Ch Type Duplex Speed Neg Flow
Control
Back
Pressure
Link
State
--- ---- ----- --- ----- ------- ------- ------
1 1000 Full 1000 Off Off Disable Up
