Configuring System Information 185
• Management IP Address — Indicates the management IP address that is advertised from the
interface.
•
Use Default — Indicates that information included in the TLVs is per the device defaults.
The possible field values are:
–
Checked — Enables sending the device default LLDP advertisements.
–
Unchecked — Indicates that the device LLDP advertisement settings are disabled, and LLDP
advertisement settings are user defined. This is the default value.
The LLDP Port Table page displays the LLDP Port Configuration. To open the LLDP Port Table,
click Security
→ LLDP → Port Settings → Show All in the tree view.
Figure 6-72. LLDP Port Table
Table 6-40. LLDP Port settings CLI Commands
The following is an example of the CLI commands:
CLI Command Description
clear lldp rx interface Restarts the LLDP RX state machine
and clearing the neighbors table
lldp optional-tlv
tlv1 [tlv2
… tlv5]
Specifies which optional TLVs from the
basic set should be transmitted
lldp enable [rx | tx | both] To enable Link Layer Discovery
Protocol (LLDP) on an interface.
Console(config)# interface ethernet g5
Console(config-if)# lldp enable
