Dell PowerConnect 5424 User Manual

Configuring Device Information 297
Configuring Static Address Parameters Using CLI Commands
The following table summarizes the equivalent CLI commands for configuring static address parameters
as displayed in the Static MAC Address page.
The following is an example of the CLI commands:.
Table 7-16. Static Address CLI Commands
CLI Command Description
bridge address mac-address { ethernet
interface | port-channel port-channel-
number
} [ permanent | delete-on-reset |
delete-on-timeout | secure ] ]
Adds a static MAC-layer station source
address to the bridge table.
show bridge address-table [vlan vlan]
[ethernet interface | port-channel port-
channel-number]
Displays entries in the bridge-forwarding
database.
Console# show bridge address-table
Aging time is 300 sec
vlan mac address port type
---- ------------ ---- --------
1
00:60:70:4C:73:FF
g8
dynamic
1
00:60:70:8C:73:FF
g8
dynamic
200
00:10:0D:48:37:FF
g9
static
g8 00:10:0D:98:37:88
g8
dynamic

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
