Configuring Device Information 353
Defining Link Aggregation Global Parameters
1 Open the LACP Parameters page.
2 Complete the LACP System Priority field.
3 Click Apply Changes .
The parameters are defined, and the device is updated.
Defining Link Aggregation Port Parameters
1 Open the LACP Parameters page.
2 Complete the fields in the Port Parameters area.
3 Click Apply Changes .
The parameters are defined, and the device is updated.
Displaying the LACP Parameters Table
1 Open the LACP Parameters page.
2 Click Show All .
The
LACP Parameters Table opens.
Configuring LACP Parameters Using CLI Commands
The following table summarizes the equivalent CLI commands for configuring LACP parameters as
displayed in the LACP Parameters page.
Table 7-36. LACP Parameters CLI Commands
CLI Command Description
lacp system-priority value Configures the system priority.
lacp port-priority value Configures the priority value for physical ports.
lacp timeout {long | short} Assigns an administrative LACP timeout.
show lacp ethernet interface [parameters |
statistics | protocol-state]
Displays LACP information for ethernet ports.
