Dell PowerConnect 5424 User Manual

420 Configuring Quality of Service
Assigning Queue Setting Using the CLI Commands
The following table summarizes the equivalent CLI commands for configuring fields in the QoS Queue
Settings page.
The following is an example of the CLI commands:
Table 9-6. Queue Settings CLI Commands
CLI Command Description
wrr-queue bandwidth weight1
weight2 . weight_n
Assigns Weighted Round Robin
(WRR) weights to egress queues.
show qos interface [ethernet
interface-number] [queuing]
Displays interface QoS data.
Console (config)# wrr-queue bandwidth 10 20 30 40
Console (config)# exit
Console # exit
Console> show qos interface ethernet g1 queueing
Ethernet g1
wrr bandwidth weights and EF priority:

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
