SC-P6500D Series/SC-T6500DE Series/SC-T3700D
Series/SC-T3700DE Series
WD1D2
1505 mm 1129 mm Secure up to 1600 mm
plus the working space.
The space required
depends on the cut
sheets/poster board being
used.
SC-P6500E Series/SC-T3700E Series
WD1D2
1505 mm 829 mm Secure up to 1600 mm
plus the working space.
The space required
depends on the cut
sheets/poster board being
used.
*1 : For the SC-P6500E Series/SC-T3700E Series,
secure a working space of 330 mm.
D1 : The space required when not using cut sheets/
poster board.
D2 : The space required when using cut sheets/
poster board. Secure up to 1600 mm front and
back plus the working space.
Notes when using the printer
Note the following points when using this printer to
avoid breakdowns, malfunctions, and print quality
decline.
❏ When using the printer, observe the operating
temperature and humidity range described in the
"Specifications Table".
U “Specifications Table (Except for the SC-
P8500DL Series/SC-T7700DL Series)” on
page 240
U “Specifications Table (SC-P8500DL
Series/SC-T7700DL Series Only)” on page 243
Even when the conditions above are met, you may
not be able to print properly if the environmental
conditions are not suitable for the paper. Be sure
to use the printer in an environment where the
paper's requirements are met. For more details,
see the documentation supplied with the paper.
Also, when operating in dry areas, air conditioned
environment, or under direct sunlight, maintain
the appropriate humidity.
❏ Avoid using the printer in locations with heat
sources or that are exposed to direct draughts
from ventilators or air conditioners. Failure to
observe this precaution could result in the print
head nozzles drying and clogging.
❏ The print head may not be capped (i.e., may not
move to the right-hand side) if an error occurs
and the printer is turned off without first
resolving the error. Capping is a function for
automatically covering the print head with a cap
(lid) to prevent the print head from drying out. In
this case, turn on the power and wait a while until
capping is performed automatically.
❏ When the power is on, do not remove the power
plug or cut the power at the breaker. The print
head may not be capped properly. In this case,
turn on the power and wait a while until capping
is performed automatically.
❏ Even when the printer is not in use, some ink will
be consumed for all colors by head cleaning and
other maintenance operations needed to keep the
head in good condition.
Notes when not using the
printer
If you are not using it, note the following points when
storing the printer. If it is not stored correctly, you may
not be able to print properly the next time it is used.
❏ If you do not print for a long time, the print head
nozzles may become clogged. We recommend that
you print once a week to prevent the print head
from clogging.
❏ The roller may leave an impression on paper that
is left in the printer. This can also cause wavy or
curled paper resulting in paper feeding problems
or the print head could be scratched. Remove any
paper when storing.
SC-P8500DM/SC-P8500D/SC-P6500D/SC-P6500DE/SC-P6500E/SC-T7700DM/SC-T5700DM/SC-T7700D/SC-T5700D/SC-3700D/SC-T3700DE/SC-T3700E/SC-P8500DL/SC-T7700DL Series User's Guide
Introduction
21
