E
Click (Import).
The Open screen is displayed.
F
Select the file you saved in step 3, and then click
Open.
The file extension is (.emy.
If there are no files displayed with the
extension .emy, select EMY File(*.emy) from
the drop-down menu to the right of the File
Name.
Paper information is added to the paper type
for the printer driver on this computer.
When three or more computers are connected
to one printer, repeat steps 4 to 6 for each
computer.
Using Web Config
Provides an overview of starting the software and the
functions provided.
Starting Procedure
Start the software from a web browser on a computer
or smart device that is connected to the same network
as the printer.
A
Check the IP address of the printer.
Press
on the Home screen, select the
connected network, and check the IP address.
Note:
The IP address can also be checked by printing a
network connection check report. A report can be
printed by touching the following in order from
the Home screen.
Menu - General Settings - Network Settings -
Connection Check
B
Start a Web browser on a computer or smart
device connected to the printer via the network.
C
Enter the IP address of the printer in the
address bar of the Web browser and press the
Enter or Return key.
Format:
IPv4: http://IP address of printer/
IPv6: http://[IP address of printer]/
Example:
IPv4: http://192.168.100.201/
IPv6: http://[2001:db8::1000:1]/
Note:
The initial value for the administrator user name
is blank (nothing entered), and the initial value
for the administrator password is the product’s
serial number. Check the product’s serial number
on the label on the printer.
Closing Procedure
Close the Web browser.
SC-P8500DM/SC-P8500D/SC-P6500D/SC-P6500DE/SC-P6500E/SC-T7700DM/SC-T5700DM/SC-T7700D/SC-T5700D/SC-3700D/SC-T3700DE/SC-T3700E/SC-P8500DL/SC-T7700DL Series User's Guide
Introducing the Software
35
