Parts lists, drawings and replacement

2001989-203C ApexPro™ Telemetry 7-3

Disassembly/assembly

Field replacement procedures

WARNING

EQUIPMENT DAMAGE/PERSONAL INJURY — Complete the

preparation before performing any other procedure in this chapter.

See Field replacement preparation on page 7-3.

Failure to follow this instruction could result in equipment damage

or personal injury.

Field replacement information for the following components are included in this

chapter:

 See Field replacement preparation on page 7-3.

 See Fan filter on page 7-5.

 See Drive filter on page 7-6.

 See Chassis cover on page 7-6.

 See Network card on page 7-7.

 See RAID card on page 7-8.

 See SNMP boards on page 7-11.

 See SNMP battery removal on page 7-14.

 See Drive bay on page 7-16.

 See Hard drive on page 7-18.

 See CD ROM drive on page 7-22.

 See CPU fan on page 7-23.

 See Chassis fan on page 7-24.

 See CPU boards on page 7-25.

 See Power module on page 7-30.

 See Temperature sensor on page 7-32.

Field replacement preparation

WARNING

LOSS OF FUNCTION/EQUIPMENT DAMAGE — Only a

qualified service technician should perform the procedures in this

chapter.

Failure to follow this instruction could result in loss of ATS and/or

equipment damage.
