2-8 ApexPro™ Telemetry 2001989-203C
Equipment overview
For the physical locations of the Unity Network connection ports on the back of the
ATS, refer to Views on page 2-2.
Theory of operation
ApexPro Telemetry System
The ATS is part of the ApexPro Telemetry System. The ApexPro Telemetry System
provides real-time patient data/alarms to one or more CIC Pro centers.
ApexPro telemetry provides clinicians with patient physiological information while
allowing for patient mobility.
The ApexPro Telemetry System components include:
NOTE
For information on software and hardware compatibility, see the ApexPro
Telemetry System What’s In This Release.
ATS
Overview
Provides the hardware/software connection between the ApexPro Telemetry System
and the Unity Network MC network.
The ATS runs the ApexPro host software application, which performs the following
functions:
 Analyzes data from the receiver system.
 Assigns care unit and bed numbers to receivers.
Unity Network Connection Connection Port
Unity Network MC network Network Port marked MC
Unity Network IX network Network Port marked IX
Unity Network RX network Network Port marked RX
For Channelized Telemetry For FH Telemetry
ATS ATS
CIC Pro center CIC Pro center
Receiver system Access points
Antenna system Transceiver(s)
Transmitter(s)
