Establishing an MPLS TE tunnel with RSVP-TE
To use RSVP-TE to set up an MPLS TE tunnel, enable both MPLS TE and RSVP-TE on the interfaces for the
tunnel to use on each node along the tunnel.
To establish an MPLS TE tunnel with RSVP-TE:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Enter MPLS view.
mpls N/A
3. Enable RSVP-TE for the switch.
mpls rsvp-te Disabled by default.
4. Exit to system view.
quit N/A
5. Enter interface view of MPLS
TE link.
interface interface-type
interface-number
N/A
6. Enable RSVP-TE on the
interface.
mpls rsvp-te Disabled by default.
7. Enter MPLS TE tunnel interface
view.
interface tunnel tunnel-number N/A
8. Set the signaling protocol for
setting up the MPLS TE tunnel
to RSVP-TE.
mpls te signal-protocol rsvp-te
Optional.
RSVP-TE applies by default.
9. Submit current tunnel
configuration.
mpls te commit N/A
Configuring RSVP-TE advanced features
RSVP-TE adds new objects in Path and Resv messages to support CR-LSP setup. RSVP-TE provides many
configurable options with respect to reliability, network resources, and other advanced features of MPLS
TE.
Before performing the configuration tasks in this section, be aware of each configuration objective and
its impact on your network.
Before you configure RSVP-TE advanced features, complete the following tasks:
• Configure basic MPLS.
• Configure basic MPLS TE.
• Establish an MPLS TE tunnel with RSVP-TE.
Configuring RSVP reservation style
Each LSP set up using RSVP-TE is assigned a resource reservation style. During an RSVP session, the
receiver decides which reservation style to use for this session and thus which LSPs to use.
Two reservation styles are available:
• FF style—Resources are reserved for individual senders and cannot be shared among senders on
the same session.
• SE style—Resources are reserved for senders on the same session and shared among them.
