Select Pool window
Available Pools table
DescriptionItem
Displays the pool name and pool ID.Pool Name (ID)
Displays the RAID level.RAID Level
Displays information about the pool capacity.Capacity
• Total: Total capacity of pool.
• Used: Used pool capacity.
• Used (%): Pool usage rates for pool capacity. Used (%) displays the value
which is truncated after the decimal point of the actual value.
Displays the data drive type and RPM. When the volume is the external volume,
Drive Type displays External Storage and the value of the external LDEV tier
rank.
Drive Type/RPM
Displays the pool threshold.User-Defined Threshold (%)
• Warning: Warning threshold is displayed.
• Depletion: Depletion threshold is displayed.
Displays Auto or Manual according to the Tier Management setting when Smart
Tiers or Smart Tiers Z is enabled. Displays Manual for pools other than Smart
Tier Management
Tiers or Smart Tiers Z which are available for monitoring. For other pools, a
hyphen (-) is displayed.
Displays information about subscription of the pool.Subscription (%)
• Current: Percentage of the total V-VOL capacity assigned to the pool and the
V-VOL capacity to be created.
• Limit: Percentage of the subscription limit of the pool.
Displays the Pool Properties window when selecting a row and clicking this
button
Detail
Select Pool window 275
