DescriptionItem
capacity. The total capacity of the LDEVs and Free capacity is displayed in the
Total.
Drive type and rpm in use on this LDEV.Drive Type/ RPM
For external volumes, vendor name, model name, and serial number appear.
For internal volumes, -/-/- appears.
Vendor/Model/Serial Number
Resource group name and ID of which this parity group is a member.Resource Group Name (ID)
Physical Location table
DescriptionItem
Location where the free spaces and LDEVs are assigned.Physical Location No.
Free space number. The hyphenation appears for volumes other than free spaces.Free Space No.
LDEV identifier. A hyphen (-) appears for other than LDEV IDs.LDEV ID
LDEV name. A hyphen (-) appears for volumes other than LDEVs.LDEV Name
Emulation type. A hyphen (-) appears for volumes other than LDEVs.Emulation Type
Capacity of the LDEV.Capacity
Number of paths set for the LDEV. A hyphen (-) appears for volumes other than
LDEVs.
Number of Paths
Edit SSIDs window
Use this window to select a storage system identifier whose properties can be changed.
278 LDEV GUI reference
