CAUTION: When you create the Thin Provisioning or Thin Provisioning Z pool, if you specify
Mixable for RAID level to display the Select Pool VOLs window, external volumes with the cache
mode set to disabled are not displayed in the Available Pool Volumes table because they cannot
coexist with volumes of the other RAID levels:
When you select these volumes in the Select Pool VOLs window, specify a hyphen (-) for RAID level.
Expand Pool Confirm window
Confirm proposed settings, name the task, then click Apply. The task will be added to the execution
queue.
Selected Pool table
DescriptionItem
Displays the pool name and pool ID.Pool Name (ID)
Selected Pool Volumes table
DescriptionItem
Displays LDEV identifier, which is the combination of LDKC, CU, and LDEV.LDEV ID
Displays the LDEV name.LDEV Name
Displays the pool-VOL capacity.Capacity
Displays the parity group ID.Parity Group ID
Displays RAID level. If a pool-VOL is an external volume, a hyphen (-) is displayed.RAID Level
Displays the data drive type and RPM. When the volume is the external volume,
Drive Type displays External Storage and the value of the external LDEV tier
rank.
Drive Type/RPM
Displays the emulation type.Emulation Type
324 Thin Provisioning and Smart Tiers GUI reference
