View LDEV IDs window
Use this window to view available, used, and disabled LDEV IDs in matrix format. The vertical
scale in the matrix represents the second-to-last digit of the LDEV number, and the horizontal scale
represents the last digit of the LDEV number.
In the matrix, cells of used LDEV numbers display in blue, unselectable in gray, and unused in
white. The LDEV numbers corresponding to any one of the following conditions cannot be specified:
• LDEV is already in use.
• LDEV is already assigned to another emulation group (grouped every 32 LDEVs).
• LDEV is not assigned to the user.
• If the following values are not identical when a mainframe volume or multi-platform volume is
created: - LDEV ID and the virtual LDEV ID - model/serial numbers of the virtual storage machine
and the storage system.
DescriptionItem
Emulation type selected in the Create LDEVs window. See “Emulation groups
and types” (page 277) for a list.
Usage of selected emulation type
LDEV identifier, which is the combination of LDKC, CU, and LDEV.LDEV IDs
LDKC: Indicates the LDKC number.
CU: Indicates the CU number.
276 LDEV GUI reference
