DescriptionItem
Indicates the mode that the RAID Manager user assigns to the volume. You cannot use
Remote Web Console to change modes. You must use the RAID Manager to change modes.
Mode
• Zer: Zero Read Cap mode is assigned to the volume. If the Read Capacity command
(which is a SCSI command) is issued to a volume in Zero Read Cap mode, it will be
reported that the capacity of the volume is zero.
• Inv: Invisible mode is assigned to the volume. If the Inquiry command (which is a SCSI
command) is issued to a volume in Invisible mode, it will be reported that the volume
does not exist. Therefore, the hosts will be unable to recognize the volume.
• Zer/Inv. Both Zero Read Cap mode and Invisible mode are assigned to the volume.
• Hyphen (-): No mode is assigned by RAID Manager to the volume.
Target of the operation or the name of the operation. When no operation is performed,
No Operation appears.
Operation
Also shown are the volume icons and the total number of volumes with each access attribute.
Error Detail Dialog Box
If an error occurs with Data Retention, the Error Detail dialog box appears. The Error Detail dialog
box displays error locations and error messages. For troubleshooting information related to Data
Retention, see “Troubleshooting Data Retention” (page 208).
The items and descriptions of the Error Detail dialog box follow.
DescriptionItems
Location where the error occurred. If an error relating to a volume occurred,
the LDKC number, CU number, and LDEV number (volume number) are shown.
Location
Provides the full text of the error message. For details about the solution, see
HP XP7 Remote Web Console Messages.
Error Message
Closes the Error Detail window.Close
Error Detail Dialog Box 367
